  • Kia Rio 5 Door Dimensions Kia Rio 5 Door Dimensions Kia Rio 5 Door Dimensions
  • Kia Rio 5 Door Dimensions Kia Rio 5 Door Dimensions Kia Rio 5 Door Dimensions
  • Kia Rio 5 Door Dimensions Kia Rio 5 Door Dimensions Kia Rio 5 Door Dimensions
Prev
Dimensions (mm)
table fix area
Car
Overall length
Overall width
Overall height
Wheelbase
Wheeltread (front)
Wheeltread (rear)
Overhang (front)
Overhang (rear)
Leg room (front)
Leg room (rear)
Head room (front)
Head room (rear)
Shoulder room (front)
Shoulder room (rear)
Minimum ground clearance

Rio 5-door

4,065

1,725

1,460

2,580

1,512

1,517

830

655

1,070

850

987

964

1,375

1,355

150
Engine
table fix area
Displacement (cc)
Max. Power (ps/rpm)
Max. Torque (kg•m/rpm)
Mated transmission

K1.4 MPI K1.6 MPI
1,368 1,591
100 / 6,000 123 / 6,300
13.6 / 4,000 15.4 / 4,850
6M/T, 6A/T 6M/T, 6A/T

Wheel

Next

  • 14'' Steel wheel

    Steel wheel

  • 15'' Steel Wheel

    Steel Wheel

  • 15'' Alloy Wheel

    Alloy Wheel

  • 17'' Alloy wheel

    Alloy wheel
Prev
  • All information and illustrations are based on data available at the time of publication and subject to change without notice.
    Contact your local Kia dealer for current information.
